11. Dome-Light or Window Roll-Up: (•Dome-Light = 1 siren chirp / Window
Roll-UP = 2 chirps)
- Configures the alarm’s “Black/White” wire to operate the:
a.
Dome-Light: Supply a (-) output when the alarm is Disarmed to illuminate the
vehicle’s Dome-Light for 30 seconds through the use of a relay, or
b. Window Roll-Up or accessory: Supply a (-) output for 30 seconds when the
alarm is Armed to operate a Window Roll-Up module or other accessory.
12. 3rd Channel Output: (•Momentary = 1 siren chirp / Window Roll-UP =
2 chirps)
- Configures the alarm’s “Pink” wire to operate an:
a. Accessory : Supply a (-) output as long as the small “•••” button on the remote
control, is pressed & held while the vehicle’s ignition is “Off”, (max 30 seconds).
b. Window Roll-Up or accessory: Supply a (-) output for 30 seconds when the
alarm is Armed to operate a Window Roll-Up module or other accessory.
13. Ignition Door Lock/Unlock: (•On = 1 siren chirp / Off = 2 chirps)
- Configures the alarm to Lock the vehicle's doors when the ignition is turned
“On” and Unlock the vehicle’s doors when the ignition is turned “Off”.
14. “RFID” Add-On to Anti-Hijacking: (On = 1 siren chirp / •Off = 2 chirps)
- Adds an “RFID” layer to both the Ignition & Open Door activated Anti-Hijacking
features. (Note: Special RFID remote control required)
JUMPER ON SIDE OF ALARM BRAIN:
Lock Pulse Time: ( • .80 seconds = Jumper “In” / 4 seconds = Jumper “Out”)
- Determines the length of the alarm’s door lock/unlock pulse output.
0.80
Sec
4.0
Sec
