Omega OMEGA+ - Digi Modem Operation; Digi Modem PC Connection

ANT
MIC
KEY EXT.SP
C
+
-
13,8V
IN
OUT
LINE IN.
EXIT SP / line out
PC
DIGI MODEM
OMEGA+
DIGI MODEM
7
Use the microphone connector to connect OMEGA+ DIGI MODEM.
Connect the DIGI MODEM IN socket to speaker Jack socket in computer.
Connect the DIGI MODEM OUT socket to line-in Jack socket in computer.
