PN:888-45-222-W-02: 45-284-026: OM1100549
STEP 3
3
a b
C d
1
2
5
P-E
P-I
P-J
P-H
16mm Bearing
P-F
25mm Washer
P-K
P-E
65mm Washer
P-K
P-G
Spring Disc
NOTE: Part# P-G must
be concave face down for
proper assembly.
