Omnimount PLAY40

PN:888-45-222-W-02: 45-284-026: OM1100549
STEP 4
4
VESA Mounting Options (mm)
100 x 200
200 x 200
200 x 300
200 x 400
300 x 300
300 x 400
400 x 400
600 x 400
300 x 200
400 x 200
200mm (7-7/8”)
400mm (15-3/4”)
300mm (11-13/16”)
600mm (23-5/8”)
100mm (3-15/16”)
200mm (7-7/8”)
200mm (7-7/8”)
400mm (15-3/4”)
300mm (11-13/16”)
400mm (15-3/4”)
300mm (11-13/16”)
400mm (15-3/4”)
400mm (15-3/4”)
300mm (11-13/16”)
200mm (7-7/8”)
A
B
C
D
