If the speaker system distorts, one of the loudspeakers may be defective. Test the speaker system once
more with another amplifier. If the sound remains distorted, the speaker system should not be operated any
more in order to prevent further damage. Please contact your dealer.
If clacking sounds are heard from the speaker system, screws may have loosened due to the continuous
vibrations. The speaker system should be checked by a specialist. Especially for public use, the speaker
system should be checked before every operation so that the speaker system and the speakers in the
systems are always well fixed.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
Disconnectfrommainsbeforestartingmaintenanceoperation!
DANGERTOLIFE!
Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
TECHNICAL SPECIFICATIONS
11038973 AZ-212A 11038975 AZ-215A
Power supply: 230 V AC, 50 Hz ~ 230 V AC, 50 Hz ~
Power consumption (max.): 300 W 350 W
Fuse: T 3.15 A, 250 V T 3.15 A, 250 V
Rated power: 150 W RMS 200 W RMS
Program power: 300 W 400 W
Components: 12" woofer, 1" horn 15" woofer, 1" horn
Sensitivity (1 W/m): 93 dB 97 dB
Amplifier:
Nominal power output: 150 W RMS 200 W RMS
Maximum power output: 300 W 400 W
Inputs: XLR or balanced ¼" jack XLR or balanced ¼" jack
Outputs:
1 Line Out XLR XLR
Frequency-range: 60 Hz - 18 kHz 60 Hz - 18 kHz
Dimensions (H x W x D): 570 x 400 x 365 mm 690 x 470 x 445 mm
Weight: 20 kg 28 kg
Please note: Every information is subject to change without prior notice. 03.07.2008 ©
