Omnitronic BDT-5.0 - Bluetooth Receiver Mode (RX)

24
English
Bluetooth receiver mode (RX)
Loudspeaker
BDT-5.0
AUX AUX
OPTICAL OPTICAL
RX Output TX Input
5V power suply
BDT-5.0 rear
DC IN AUX AUXOPTICAL OPTICAL
AUX cable
AUX/RCA cable
Optical cable
Speaker
optical input
Speaker AUX
input
Speaker RCA
input
1
Connect the audio adapter to a power source (TV or power adapter) with the USB
cable and connect it to the TV with one of the audio cables.
RX output TX input
