00030007.DOC, Version 1.218/25
TECHNICAL SPECIFICATIONS
P
ower supply: 115/230 V AC, 50/60 Hz ~
Power consumption: 12 W
Type: Manual turntable
Drive-method: Direct-drive
M
otor: Brushless 24 V DC-motor
Speed: 33 1/3 RPM and 45 RPM
Change-time between speeds:
33 -> 45 RPM in <1 sec.
45 -> 33 RPM in <1 sec.
Pitch adjustment: ± 10 % via fader
Initial torque: >1.0 kg/cm
Start time: <1 sec.
Stop time: <1 sec.
Wow and Flutter: <0.15 % WRMS
Rumble: 55 dB DIN B
Platter: Outer diameter 330 mm
Weight 728 g
Tonearm: S-shape with Cardan's suspension
Tonearm-length: 230,5 mm
Overhang: 16 mm
Adjustable stylus-pressure 0-4 g
Anti-Skating-range: 0-7 g
Phono output level: 1.5-3.6 mV @ 1 kHz 5 cm/sec
Line output level: 90-216 mV @ 1 kHz 5 cm/sec
Frequency range: 20 Hz - 20 kHz
Channel separation: >15 dB
Output connectors: RCA, USB type B
Dimensions: 450 x 350 x 155 mm
Weight: 11 kg
Please note: Every information is subject to change without prior notice. 03.12.2008 ©
