10007125.DOC
20/20
TECHNICAL SPECIFICATIONS
Power supply: 2 x 15 V AC ~
Power consumption: 35 W
Inputs: 3 phono, 9 line, 3 aux, 7 mic
Outputs: 2 Master, 1 Booth, 1 Rec
Minimum input voltage:
Microphone: 1 mV RMS
Phono: 3 mV RMS
Line: 150 mV RMS
Aux In: 150 mV RMS
Output voltage:
Master 1: 0,75 V/1,5 V RMS or XLR
Master 2: 0,75 V/1,5 V RMS or XLR
Booth: 0,75 V/1,5 V RMS
Record: 0,75 V RMS
Headphones: 8 Ohms or more
Outputs: 2 Master-Out, 1 Rec-Out, 1 Booth-Out via RCA
Master 1 Out: via 2 additional, balanced XLR-connectors
Master 2 Out: via 2 additional, balanced XLR-connectors
Frequency range: 20 - 20 000 Hz
Distortion: <0,03 %
S/N-ratio: >65 dB
Talkover-attenuation: -15 dB
Tone control:
Treble: 10 KHz –12 dB bis +12 dB
Middle: 1 KHz –12 dB bis +12 dB
Bass: 100 Hz -12 dB bis +12 dB
Dimensions (WxDxH): 48 x 132 x 115 mm
Weight: 3.2 kg
Weight with power supply:
4.7 kg
Please note: Every information is subject to change without prior notice. 15.09.2005 ©
