00008423.DOC VERSION 3.3
31/49
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS P-125, P-250 & P-500
P-125 P-250 P-500
Power supply: 115/230 V AC, 50/60 Hz ~ 115/230 V AC, 50/60 Hz ~ 115/230 V AC, 50/60 Hz ~
Power-range: 230 V ± 10 % (206 V -
253 V)
230 V ± 10 % (206 V -
253 V)
230 V ± 10 % (206 V -
253 V)
Power consumption
(max.):
250 W 500 W 1000 W
Momentary music peak
power at 1 KHz:
200 W / 4 Ohms 400 W / 4 Ohms 650 W / 4 Ohms
Maximum power output: 2 x 70 W / 4 Ohms 2 x 140 W / 4 Ohms 2 x 295 W / 4 Ohms
Nominal power output: 2 x 65 W / 4 Ohms 2 x 125 W / 4 Ohms 2 x 250 W / 4 Ohms
Power output sine:
Stereo 4 Ohm 2 x 65 W 2 x 125 W 2 x 250 W
Stereo 8 Ohm 2 x 40 W 2 x 75 W 2 x 130 W
8 Ohms bridged 1 x 125 W 1 x 250 W 1 x 500 W
Frequency range: 22 - 31 000 Hz 22 - 31 000 Hz 22 - 31 000 Hz
Damping-factor: > 150 > 150 > 150
Distortion factor: 0,01 % 0,01 % 0,01 %
Signal to Noise Ratio: 108 dB 108 dB 108 dB
Channel seperation (at 1
KHz):
89 dB 89 dB 89 dB
Min. input sensitivity: 0,77 V/26 dB/1,44 V 0,77 V/26 dB/1,44 V 0,77 V/26 dB/1,44 V
Input impedance: 12 kOhms (unbalanced),
22 kOhms (balanced)
12 kOhms (unbalanced),
22 kOhms (balanced)
12 kOhms (unbalanced),
22 kOhms (balanced)
Output impedance: > 0,02 Ohms > 0,02 Ohms > 0,02 Ohms
Slew-rate: > 35 V/µsec > 35 V/µsec > 30 V/µsec
Input-connectors: 2 x XLR-female-plug, 2 x
1/4"-jack-plug
2 x XLR-female-plug, 2 x
1/4"-jack-plug
2 x XLR-female-plug, 2 x
1/4"-jack-plug
Output-connectors: 2 x Speaker (stereo), 1 x
Speaker (bridge), 2 x
Banana/screw
combination
2 x Speaker (stereo), 1 x
Speaker (bridge), 2 x
Banana/screw
combination
2 x Speaker (stereo), 1 x
Speaker (bridge), 2 x
Banana/screw
combination
Control elements: Power switch, input
attenuators (one per
channel), Mode switch -
Stereo/Parallel/Bridged,
Ground Lift, Input-Level-
Select (0.77 V/26 dB/1.44
V), limiter
Power switch, input
attenuators (one per
channel), Mode switch -
Stereo/Parallel/Bridged,
Ground Lift, Input-Level-
Select (0.77 V/26 dB/1.44
V), limiter
Power switch, input
attenuators (one per
channel), Mode switch -
Stereo/Parallel/Bridged,
Ground Lift, Input-Level-
Select (0.77 V/26 dB/1.44
V), limiter
LED indicators (per
channel):
Power, Protect, Signal,
Mode
Power, Protect, Signal,
Mode
Power, Protect, Signal,
Mode
Protection circuits: Short-circuit, DC-
protection-circuit, Thermal
protection-circuit, Softstart
Short-circuit, DC-
protection-circuit, Thermal
protection-circuit, Softstart
Short-circuit, DC-
protection-circuit, Thermal
protection-circuit, Softstart
Construction: Steel chassis, aluminium
frontpanel
Steel chassis, aluminium
frontpanel
Steel chassis, aluminium
frontpanel
Dimensions: 325 x 482 x 54 mm 375 x 482 x 100 mm 445 x 482 x 100 mm
Minimum mounting depth: 330 mm 380 mm 450 mm
Weight: 5.4 kg 7.2 kg 10.25 kg
