TECHNICAL SPECIFICATIONS P-1000, P-1500 & P-2000
P-1000 P-1500 P-2000
Power supply: 115/230 V AC, 50/60 Hz ~ 115/230 V AC, 50/60 Hz ~ 115/230 V AC, 50/60 Hz ~
Power-range: 230 V ± 10 % (206 V -
253 V)
230 V ± 10 % (206 V -
253 V)
Power consumption
(max.):
1175 W 1675 W 2875 W
Momentary music peak
power at 1 KHz:
1270 W / 4 Ohm 1950 W / 4 Ohm
Maximum power output: 2 x 582 W / 4 Ohm 2 x 840 W / 4 Ohm
Nominal power output: 2 x 500 W / 4 Ohm 2 x 750 W / 4 Ohm 2 x 1000 W / 4 Ohm
Power output sine:
Stereo 4 Ohm 2 x 500 W 2 x 750 W 2 x 1000 W
Stereo 8 Ohm 2 x 245 W 2 x 390 W 2 x 625 W
8 Ohms bridged 1 x 850 W 1 x 1250 W 1 x 1875 W
Frequency range: 22 - 31 000 Hz 20 - 31 000 Hz 20 - 40 000 Hz
Damping-factor: > 200 > 200 > 400
Distortion factor: 0,01 % 0,01 % 0,01 %
Signal to Noise Ratio: 108 dB 108 dB 90 dB
Channel seperation (at 1
KHz):
89 dB 89 dB 70 dB
Min. input sensitivity: 0,77 V/26 dB/1,44 V 0,77 V/26 dB/1,44 V 0,77 V/26 dB/1,4 V
Input impedance: 12 kOhms (unbalanced),
22 kOhms (balanced)
12 kOhms (unbalanced),
22 kOhms (balanced)
20 kOhms (balanced)
Output impedance: > 0,02 Ohms > 0,02 Ohms > 0,02 Ohms
Slew-rate: > 35 V/µsec > 40 V/µsec 60 V/µsec
Input-connectors: 2 x XLR-female-plug, 2 x
1/4"-jack-plug
2 x XLR-female-plug, 2 x
1/4"-jack-plug
2 x XLR-female-plug, 2 x
1/4"-jack-plug
Output-connectors: 2 x Speakon (stereo), 1 x
Speakon (bridge), 2 x
Banana/screw
combination
2 x Speakon (stereo), 1 x
Speakon (bridge), 2 x
Banana/screw
combination
2 x Speakon (stereo), 1 x
Speakon (bridge), 2 x
Banana/screw
combination
Control elements: Power switch, input
attenuators (one per
channel), Mode switch -
Stereo/Parallel/Bridged,
Ground Lift, Input-Level-
Select (0,77 dB, 1,44 dB,
0 dB)
Power switch, input
attenuators (one per
channel), Mode switch -
Stereo/Parallel/Bridged,
Ground Lift, Input-Level-
Select (0,77 dB, 1,44 dB,
0 dB)
Power switch, input
attenuators (one per
channel), Mode switch -
Stereo/Parallel/Bridged,
Ground Lift, Input-Level-
Select (0,77 dB, 1,44 dB,
0 dB)
LED indicators (per
channel):
Power, Protect, Signal,
Mode
Power, Protect, Signal,
Mode
Power, Protect, Signal,
Mode
Protection circuits: Short-circuit, DC-
protection-circuit, Thermal
protection-circuit, Softstart
Short-circuit, DC-
protection-circuit, Thermal
protection-circuit, Softstart
Short-circuit, DC-
protection-circuit, Thermal
protection-circuit, Softstart
Construction: Steel chassis, aluminium
frontpanel
Steel chassis, aluminium
frontpanel
Steel chassis, aluminium
frontpanel
Dimensions: 435 x 482 x 99 mm 435 x 482 x 99 mm 545 x 482 x 97 mm
Weight: 16,7 kg 23 kg 23 kg
Power/weight-relation: 30 W/kg 33 W/kg 43 W/kg
Please note: Every information is subject to change without prior notice. 06.06.2003 ©
