There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
7.1 Replacing the crossfader
Procedure:
Step 1: Remove the fader knob.
Step 2: Remove the two outer screws on the fader panel.
Step 3: Take the fader out and unplug the connection cable.
Step 4: Connect the new fader and fix it in the unit.
8.TECHNICAL SPECIFICATIONS
Power supply: 15 V AC, 500 mA (mixer)
230 V AC, 50 Hz ~ (power supply unit)
Power consumption: 5 W
Inputs:
DJ MIC: 6.3 mm jack
Minimum input voltage: 1.5 mV RMS/ 1 kohm
LINE 1-2: stereo RCA
Minimum input voltage: 150 mV RMS/ 270 kohm
PHONO 1-2: stereo RCA
Minimum input voltage: 3 mV RMS/ 470 kohm
Outputs:
MASTER: stereo RCA
Max. output level: +22 dBu
Output voltage: 9 V RMS
REC: stereo RCA
Output voltage: 225 mV RMS/ 5 kohm
Headphones: 6.3 mm stereo jack/ 16 ohm
Tone control:
2x High: -26 dB to +12 dB/ 12 KHz
2x Middle: ±15 dB/ 2.5 KHz
2x Low: -26 dB to +12 dB/ 80 Hz
S/N ratio: >80 dB
Frequency range: 20-20,000 Hz
Distortion: <0.02% (line/phono)
Dimensions (WxHxD): 262 x 255 x 84 mm
Weight: 2.8 kg
Please note: Every information is subject to change without prior notice. 30.04.2008 ©
