CowlPartAssembly
Ø Cowl,Propeller,SpinnerInstallation
1. Installcowltofuselage(pleasetakenotethatmotor
mustbeincenterposition)
2. Removethepropellerspinneradapterandscrewgasket,
installthealuminumspinnerback‐plate,propeller,
propellerspinneradapterandscrewgasketin
succession.
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
3. Securethespinnerwithscrews,pleasepayattention
thatspinnermustbelocatedinthecentrepositionof
thecowl,andspinneredgeisparalleltothecowl,gapis
about1.5mm.
4. Securethecowlwithscrews,twoscrewsforeachoftwo
sides.secure
