74”Edge540BalsawoodAirplane
ParameterSpecification
Rate EXP Direction Throw
Aileron
High 35~40% Up
36~39°
Low 40~45% Down
20~26°
Elevator
High 38~45% Up
45~53°
Low 45~55% Down
30~35°
Rudder
High 38~45% Up
42~50°
Low 45~55% Down
28~32°
RecommendedSettingsofDualRatesandExponentialsofControlSurfaces
Item: 74”EDGE540
Color:
Green▢ Red▢ 
Yellow▢ Orange▢
WingSpan: 1880mm(75in) FullLength: 1800mm(72in)
FlightWeight: 4.8~5.3KG TheCenterofGravity(CG): Approx.120-135mm
WingArea:
70.51g/d㎡
WingLoad:
68~75.1g/d㎡
WingAngleofIncidence:
0°
MotorThrustAngles:
Down0°&Right2°
PackageDimension 144*56*30(L*H*W)cm GrossWeight: 15.3kg
Servo:20~35Kg*5(Aileron*2,Elevator*1Rudder*1Throttle*1)
GasPower(Recommended):30-35CC,Propeller:19x8/19x9/19x10/20x8/20x9
ElectricPower(Recommended):
Option1:Motor:Sunnysky7015,ESC:X120A,Propeller:20x8/20x9,Lipo8s4000mah/12s3300mah3700mah4000mah
Option2:Motor:Sunnysky6220,ESC:X120A,Propeller:20x8/20x9;Lipo6S5000mah/8s3300mah3700mah4000mah
