WingsAssembly
3. Pulloutthewhitepolyesterthreadfromtheservoholewith
tweezers,tieupwithaileronservoconnector.
Ø AileronServoInstallation
1. Carefullylocatetheslotwhichhasbeenmadeonthewing
tail,lightlycutthroughthecoveringbutnotintothebalsa
sheeting.
2. Usesandpapertoroughentherootofcontrolarm.Tryto
insertitintothemountingslottoadjustthepositionatfirst,
thentakeitout,applygluetotheslotandtherootofthe
controlarm,insertittotheslottosecureit.
ZhuhaiEdgeSmartDriveTechnologyCo.,Ltd.
www.omphobby.com
4. Findtheotherheadofwhitepolyesterthreadfromwingside,
pullituntilaileronservoisplacedinservohole.
