5. Removeblackrubberringfromthewingside,pass
aileronservowireintotheblackrubberringand
secureittotheoriginalposition.
WingsAssembly
6. Secureaileronservoarmandcontrolarmswithballhead
pullrod,putthecupheadhexagonalscrew,gasket,ballhead
onservoarm,secureitwithironpliers,adjusttheballhead
pullrodstoproperlength.
7. Securescrew,washer,ballheadtocontrolarm,controlarmis
at90degreesagainstservo.
8. Checkthedegreesbetweenservoarmandcontrolarms.
