OMP Hobby M2 Evo - Assembly Step 6: Tail Section Assembly; Tail Boom and Vertical Stabilizer Mounting

step 6 步骤六
󰷂六󲾣󲶋
M1.6x3mm
󰈏󱬆󰴋
3K 碳纤维垂直翼
󰷂六󲾣󲶋
(M1.6x4mm)x3
󰷂六󲾣󲶋
(M1.6x3mm)x2
󰷂六󲾣󲶋
M2x14mm
Socket screw Socket screw
Tail Motor
Socket screw
3K CF Vertical Stabilizer
󰷂六󲾣󲶋
M1.6x6mm
Socket screw
󰷂六󲾣󲶋
M1.6x4mm
Socket screw
󰈏󱬆󰴋󰅫󰑸󰔋󱠘
Tail Motor
Reinforcement Plate
󰷂六󲾣󲶋
(M1.6x6mm)x2
Socket screw
󰈏󲅲󳚹󰅫
Tail Boom inner Mount
block
尾管
Tail Boom
M2 󳰃󰵏󲶋󱆞
M2 Nut
Hexagon socket
head M2*14(9mm)
11
