OMP Hobby M2 Evo - Assembly Step 5: Landing Gear Installation; Landing Skid Mount and Skid Attachment

step 5 步骤五
󲛫󰶇󰅫󰑸
󲛫󰶇
Landing skid mount
Landing skid
󱠘
Ø1.6xØ3.5x0.4mm
Washer
󰷂󲾣󲶋
M1.6x8mm
Socket screw
󰷂󲾣󲶋
(M1.6x8mm)x4
󰷂󲾣󲶋
(M1.6x4mm)x10
󰷂󲾣󲶋
(M2x4mm)x4
Socket screw
Socket screw
Socket screw
󱠘 (Ø1.6xØ3.5x0.4mm )x4
Washer
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰵐󰬀󰷂
Side plate struts
󰴋󲔺󲛫󰶇󳰃󰵏
Landing Skids lock pad

O-ring
10
EN
