OMP Hobby M2 Evo - Assembly Step 4: Swashplate Mechanism; Swashplate and Auxiliary Arm Assembly

step 4 步骤四
󰷂󲾣󲶋
M2x10mm-L4
M2 󳰃󰵏󲶋󱆞
Socket screw
M2 Nut
󰭭󱲩
Swash plate
󰷂󲾣󲶋
M2x8mm
Socket screw
󱧔󲶋
Ball screws
󱠘
Ø2xØ3.5x0.3mm
Washer
󱒫󱦱󳕅󰡐

Bearing
󰭭󱲩󰬀󰶇
Tilt tray bracket
󳫑󳕅

Pin Shaft
󲶋󳎮󳕖󲞓
Pros and Cons auxiliary arm
󰷂󲾣󲶋
(M2x8mm)x2
󰷂󲾣󲶋
(M2x10mm-L4)x1
󰷂󲾣󲶋
(M2x4mm)x4
Socket screw
Socket screw
Socket screw
󱠘 (Ø2xØ3.5x0.3mm )x4
Washer
9
EN
WWW.OMPHOBBY.COM
󱠘
Ø2xØ3.5x0.4mm
Washer
󱠘 (Ø2xØ3.5x0.4mm )x2
Washer
