OMP Hobby M2 Evo - Assembly Step 3: Fuselage Structure; Fuselage Frame and Flight Control Board

8
EN
WWW.OMPHOBBY.COM
step 3 步骤三
󰴋󰅫󰷂
󰴋󳑼󰔋󰵐
Canopy Fixed Bolt
Frame Rear carbon
Reinforcement Plate
set
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󱬆󱈱󰑦󰵐
battery lower panel set
󱬆󱈱󳰡
Battery phase panel
󰴋󳑼󰵐
󰴋󳑼󰎷󰵐
Fuselage Lower Left
Carbon Fiber Board set
Fuselage lower Right Carbon
Fiber Board set
󰷂󲾣󲶋
M1.6x4mm
Socket screw
󰷂󲾣󲶋
(M1.6x4mm)x6
Socket screw
󳺯󰥸󰴋󳑼󲛇󰅫󰑸
Flight Control Mounting
Panel
󰷂󲾣󲶋
M1.7x6mm
Socket screw
󰷂󲾣󲶋
M1.7x4mm
Socket screw
󰷂󲾣󲶋
M1.7x4mm
Socket screw
󰷂󲾣󲶋
M1.7x6mm
Socket screw
󰷂󲾣󲶋
(M1.7x4mm)x4
Socket screw
󰷂󲾣󲶋
(M1.7x6mm)x2
Socket screw
󱬆󱈱󳰡
Fuselage Lower
Carbon panel(RoHS)
