step 9 步骤九
连杆约28.2mmx3
CH3 连杆
CH1 连杆
CH2 连杆
约SS
约 10
飞控
双面胶
注意：先将双面减震胶与接收机板
完全贴合好，再安装飞控。飞控必
须与机身完全平行，以达到最佳的
飞行效果。
!
注意
CAUTION
Linkage rod
Approx.28.2mmx3
CH2 Linkage rod
CH1 Linkage rod
CH3 Linkage rod
Flight Control
Double-sided tape
Note:Fist,the double-sided damping rubber
should be fully fitted with the receiver board,
and then install the flight control.The flight
control must be completely parallel to the
fuselage to achieve the best flight performance.
