Cowl and Engine Assembly
Ø Motor Installation
1. Unscrew socket head screws from the head plate of fuselage.
2. Put the screws into motor mount and put aluminum columns
to the other side of screws.
3. Apply glue to the screws and install motor to motor holder.
Zhuhai Edge Smart Drive Technology Co., Ltd.
www.omphobby.com
Ø ESC Installation
1. Attach the connected ESC to ESC holder with double-sided tape
and Secure with cable ties.
2. Tie the wires of ESC and motor with fastening strap.
To Next Page
