Omron 3F88L-160 Connection Manual

Connection manual of XDesignerPlus external devices
11 / 12
Address
Name
Detailed information
32 BIT available
0020
to
002B
Bank2
Same as for bank1
Address 0020 to 0023 : Bank 2 cam data protect setting
Address 0024 to 0027 : Bank 2 one-direction function setting
Address 0028 to 002B : Bank 2 rotation direction setting
X
0030
to
003B
Bank3
Same as for bank1
Address 0030 to 0033 : Bank 3 cam data protect setting
Address 0034 to 0037 : Bank 3 one-direction function setting
Address 0038 to 003B : Bank 3 rotation direction setting
X
0040
to
004B
Bank4
Same as for bank1
Address 0040 to 0043 : Bank 4 cam data protect setting
Address 0044 to 0047 : Bank 4 one-direction function setting
Address 0048 to 004B : Bank 4 rotation direction setting
X
0050
to
005B
Bank5
Same as for bank1
Address 0050 to 0053 : Bank 5 cam data protect setting
Address 0054 to 0057 : Bank 5 one-direction function setting
Address 0058 to 005B : Bank 5 rotation direction setting
X
0060
to
006B
Bank6
Same as for bank1
Address 0060 to 0063 : Bank 6 cam data protect setting
Address 0064 to 0067 : Bank 6 one-direction function setting
Address 0068 to 006B : Bank 6 rotation direction setting
X
0070
to
007B
Bank7
Same as for bank1
Address 0070 to 0073 : Bank 7 cam data protect setting
Address 0074 to 0077 : Bank 7 one-direction function setting
Address 0078 to 007B : Bank 7 rotation direction setting
X
0080
to
008B
Bank8
Same as for bank1
Address 0080 to 0083 : Bank 8 cam data protect setting
Address 0084 to 0087 : Bank 8 one-direction function setting
Address 0088 to 008B : Bank 8 rotation direction setting
X
0100
Clear Command
Program Clear, Parameter Clear, and Parameter Update
X
1000
to
12CF
Cam Programs
for Cams1 to 8
of Bank 1
Program status
0 : Output OFF / 1 : Output ON
Address 1000 : Cam 1~8 angle 0 state ▪▪▪ Address 12CF : Cam 1~8 angle 719 state
X
1300
to
15CF
Cam Programs
for Cams9 to 16
of Bank 1
Program status
0 : Output OFF / 1 : Output ON
Address 1300 : Cam 9~16 angle 0 state ▪▪▪ Address 15CF : Cam 9~16 angle 719 state
X
1600
to
18CF
Cam Programs
for Cams17 to
24 of Bank 1
Program status
0 : Output OFF / 1 : Output ON
Address 1600 : Cam 17~24 angle 0 state ▪▪▪ Address 18CF : Cam 17~24 angle 719 state
X
1900
to
1BCF
Cam Programs
for Cams25 to
32 of Bank 1
Program status
0 : Output OFF / 1 : Output ON
Address 1900 : Cam 25~32 angle 0 state ▪▪▪ Address 1BCF : Cam 25~32 angle 719 state
X
2000
to
2BCF
Cam Programs
for Bank 2
Same as for Bank 1
X
3000
to
3BCF
Cam Programs
for Bank 3
Same as for Bank 1
X
4000
to
4BCF
Cam Programs
for Bank 4
Same as for Bank 1
X
500
to
5BCF
Cam Programs
for Bank 5
Same as for Bank 1
X
