Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit
X38
Latest Alarm Info. Running Status
3
Bit15: ---
Bit14: OL (Overload warning)
Bit13: LOC (Light load detec-
tion)
Bit12: OL2 (Overload warning
2)
Bit11: OLP (During active
drive)
Bit11: OLP (During active
drive)
Bit10: LIFE (Life warning)
Bit9: OHF (Fin Overheat warn-
ing)
Bit8: TR
Y (During retry)
Bit7: FAN (Fan operation sig-
nal)
Bit6: REF (RUN command
source)
Bit5: THM (Thermal warning)
Bit4: IPF (During restart after
instantaneous power failure)
Bit3: SETM (2nd motor selec-
tion)
Bit2: IRDY (Operation ready)
Bit1: FDT1 (Over set Frequen-
cy arrival)
Bit0: FAR1 (Constant speed
arrival)
0 - -
X49 Fault Counter
0 to 65535
0 - -
X60
Last Info. Alarm Info. Output Fre-
quency
0.00 to 655.35 Hz
0 - Hz
X61 Last Alarm Info. Output Current
0.00 to 99.99A
0 - A
X62 Last Alarm Info. Output Voltage
0 to 1000 V
0 - V
X63 Last Alarm Info. Torque Monitor
-999 to 999
0 - %
4 Parameter List
4-63
M1 Series Standard Type User's Manual (I669)
4-1 List of Monitors by Group
4
4-1-4 Parameter X (Alarm Information 2)
