Omron 3G3M1-A Series - Page 77

Applicable model Terminal arrangement
3G3M1-AB001/
AB002/AB004/AB007
3G3M1-A2001/
A2002/A2004/A2007
P1 P(+) N(-)
DB U V
W
G G
L1/R
6.7
(0.26)
6.7
(0.26)
6.7
(0.28)
6.7
(0.26)
6.7
(0.26)
6.7
(0.26)
L3/TL2/S
6.8
(0.27)
6.8
(0.27)
6.7
(0.26)
6.7
(0.26)
6.7
(0.26)
6.7
(0.26)
(For single-phase class, connect L1/L to L1/R and L2/N to L3/T.)
3G3M1-AB015
3G3M1-A2015/A2022
3G3M1-A4004/
A4007/A4015/A4022
P1 P(+) N(-)
DB U V
W
G G
L1/R
9
(0.35)
9
(0.35)
9
(0.35)
10
(0.39)
10
(0.39)
10
(0.39)
L3/TL2/S
10.17
(0.40)
10.17
(0.40)
9
(0.35)
9
(0.35)
9
(0.35)
9
(0.35)
(For single-phase class, connect L1/L to L1/R and L2/N to L3/T.)
3G3M1-AB022
3G3M1-A2037
3G3M1-A4030/A4040
P1 P(+) N(-)
DB U V
W
G G
L1/R
9
(0.35)
9
(0.35)
9
(0.35)
10
(0.39)
10
(0.39)
10
(0.39)
L3/TL2/S
10.17
(0.40)
10.17
(0.40)
9
(0.35)
9
(0.35)
9
(0.35)
9
(0.35)
(For single-phase class, connect L1/L to L1/R and L2/N to L3/T.)
2 Design
2-17
M1 Series Standard Type User's Manual (I669)
2-3 Wiring
2
2-3-4 Wiring for Main Circuit Terminals
