C200H Systems Section 2-2
15
Example System 1: One Master
Slave Rack Slave Rack Slave Rack
Slave RackSlave Rack
C200H SlaveC200H Master
C200H PC
Example System 2: Two Masters
Remote
Interface
I/O Block
Remote T
erminal
Slave Rack Slave Rack
Slave Rack
Slave Rack
C200H PC
Expansion
I/O Rack
C200H Master
C200H Master
Slave Rack
A maximum of two C200H Expansion I/O Racks can be connected to a Slave
Rack. I/O Connecting Cable (2-conductor cable) is used to connect the extra
Expansion I/O Racks.
Example System 3: Master
with Extra Expansion I/O
Racks
