Appendix AStandard Models
107
H-PCF Optical Fiber Cables (For SYSMAC NET, SYSMAC LINK, and SYSMAC BUS)
Name Specifications Model number Stan-
dards
Optical Fiber Cables
10 m, black
Composite
S3200-HCLB101 ---
SYSMAC NET, SYSMAC LINK
50 m, black
cable including
two-core cable
S3200-HCLB501
100 m, black
and two-core
S3200-HCLB102
500 m, black
power supply
cable
S3200-HCLB502
1,000 m, black
S3200-HCLB103
10 m, orange S3200-HCLO101
50 m, orange S3200-HCLO501
100 m, orange S3200-HCLO102
500 m, orange S3200-HCLO502
1,000 m, orange S3200-HCLO103
Optical Fiber Cables
10 m, black Two-core cable S3200-HCLB101 ---
SYSMAC NET, SYSMAC LINK,
SYSMAC BUS
SYSMAC WAY
50 m, black S3200-HCCB501
,
100 m, black S3200-HCCB102
500 m, black S3200-HCCB502
1000 m, black S3200-HCCB103
10 m, orange S3200-HCCO101
50 m, orange S3200-HCCO501
100 m, orange S3200-HCCO102
500 m, orange S3200-HCCO502
1,000 m, orange S3200-HCCO103
10 m, black Two-core cord S3200-HBCB101 ---
50 m, black S3200-HBCB501
100 m, black S3200-HBCB102
500 m, black S3200-HBCB502
1,000 m, black S3200-HBCB103
Optical Fiber Cable Connector
SYSMAC NET:
S3200-LSU03-01E
B700-AL001
C500-SNT31-V4
Full-lock con-
nector for NSU,
NSB,, and C500
SYSMAC NET
Link Unit
S3200-COCH62M ---
SYSMAC BUS:
C200H-RM001-PV1
C200H-RT001/RT002-P
C500-RM001-(P)V1
C500-RT001/RT002-(P)V1
3G2A9-jjj(-P)
Half-lock con-
nector for Re-
mote I/O Mas-
ter, Remote I/O
Slave, Host Link
Unit, and Link
Adapter
S3200-COCH82
SYSMAC NET/SYSMAC LINK
C200HS-SNT32
C200HW-SLK13/14
Half-lock con-
nector
S3200-COCF2511
SYSMAC NET/SYSMAC LINK
CV500-SNT31
CV500-SLK11
CV1000H-SLK11
Full-lock con-
nector
S3200-COCF2011
To relay at all SYSMAC NET
COCF62M and
S3200-COCF62M
no
es.
are
used as a pair.
S3200-COCF62F
Note: 1. Optical fiber cables must be prepared and connected by specialists.
