Omron C200HS Series User Manual

I/O Memory Allocation Section 9-3
208
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A299 All Program
Address
Where
Program
Stopped
(Leftmost 4
digits)
(A294 contains the task number
of the task where program exe-
cution was stopped.)
Left 4 digits
of the pro-
gram ad-
dress
Same as
CS/CJ-series
PLC.
A300 All Error Log
Pointer
When an error occurs, the Error
Log Pointer is incremented by 1
to indicate the location where the
next error record will be recorded
as an offset from the beginning
of the Error Log Area (A100 to
A199).
The Error Log Pointer can be
cleared to 00 by turning A50014
(the Error Log Reset Bit) from
OFF to ON.
When the Error Log Pointer has
reached 14 (20 decimal), the
next record is stored in A195 to
A199 when the next error occurs.
00 to 14
hexadeci-
mal
Same as
CS/CJ-series
PLC.
A301 All Current EM
Bank
This word contains the current
EM bank number in 4-digit hexa-
decimal. The current bank num-
ber can be changed with the
EMBC(281) instruction.
0000 to
000C
hexadeci-
mal
Same as
CS/CJ-series
PLC.
A302 A30200
to
A30215
CS/CJ-
series CPU
Bus Unit
Initializing
Flags
These flags are ON while the
corresponding CS/CJ-series
CPU Bus Unit is initializing after
its CS/CJ-series CPU Bus Unit
Restart Bit
(A50100 to A50115) is
turned from OFF to ON or the
power is turned ON.
Bits 00 to 15 correspond to unit
numbers 0 to 15.
0: Not ini-
tializing
1: Initializ-
ing
(Reset to 0
automati-
cally after
initializa-
tion.)
Not used.
A330 to
A335
A33000
to
A33515
Special I/O
Unit Initial-
izing Flags
These flags are ON while the
corresponding Special I/O Unit is
initializing after its Special I/O
Unit Restart Bit
(A50200 to
A50715
) is turned from OFF to
ON or the power is turned ON.
The bits in these words corre-
spond to unit numbers.
0: Not ini-
tializing
1: Initializ-
ing
(Reset to 0
automati-
cally after
initializa-
tion.)
Not used.
A339
and
A340
All Maximum
Differentia-
tion Flag
Number
These words contain the maxi-
mum value of the differentiation
flag numbers being used by dif-
ferentiation instructions.
Same as
CS/CJ-series
PLC.
