I/O Memory Allocation Section 9-3
216
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A40207 CS/CJ-
series CPU
Bus Unit
Error Flag
(Non-fatal
error)
ON when an error occurs in a
data exchange between the CPU
Unit and a CS/CJ-series CPU
Bus Unit (including an error in the
CS/CJ-series CPU Bus Unit it-
self).
The CPU Unit will continue oper-
ating and the ERR/ALM indicator
on the front of the CPU Unit will
flash. The CS/CJ-series CPU
Bus Unit where the error oc-
curred will stop operating and the
unit number of the Unit where the
data exchange error occurred is
indicated in A417.
(This flag will be turned OFF
when the error is cleared.)
1: Error in
one or
more Units
0: No error
in any Unit
Not used.
A40208 Inner Board
Error Flag
(Non-fatal
error)
ON when an error occurs in a
data exchange between the CPU
Unit and the Inner Board (includ-
ing an error in the Inner Board
itself).
The CPU Unit will continue oper-
ating and the ERR/ALM indicator
on the front of the CPU Unit will
flash. The Inner Board will stop
operating and details on the error
will be written to A424.
(This flag will be turned OFF
when the error is cleared.)
1: Error
0: No error
Not used.
A40209 I/O Verifi-
cation Error
Flag
(Non-fatal
error)
ON when a Basic I/O Unit regis-
tered in the I/O Table does not
match the Basic I/O Unit actually
installed in the PLC because a
Unit was added or removed.
1: Mis-
match
0: No mis-
match
Not used.
A40210 PLC Setup
Error Flag
(Non-fatal
error)P
ON when there is a setting error
in the PLC Setup. The CPU Unit
will continue operating and the
ERR/ALM indicator on the front
of the CPU Unit will flash.
The location of the error will be
written to A406.
(This flag will be turned OFF
when the error is cleared.)
1: Error
0: No error
Same as
CS/CJ-series
PLC.
A402
A40212 Basic I/O
Unit Error
Flag
(Non-fatal
error)
ON when an error has occurred
in a Basic I/O Unit (including
C200H Group-2 High-density I/O
Units and C200H Interrupt Input
Units).
1: Error
0: No error
Not used.
