<Target value comparison table>
Linear mode
S
S+1
Number of target values
Target value #1, lower 4 digits
Target value #1, upper 4digits
Subroutine number
S+2
S+3
(BCD 4 digits) 0001 to 0048
(BCD 8 digits) F8388608
to 08388607
(Incremental) 0000 to 0255
(Decrement) F000 to F255
CQM1H
Number of target values
Lower word of target value 1
Upper word of target value 1
Interrupt task number for target value 1
(BIN 4 digits) 0001 to 0030Hex
(BIN 8 digits) 80000000
to 7FFFFFFF
(Incremental) 0000 to 00FF
(Decrement) 8000 to 80FF
CJ1M/CJ2M
S+142
Target value #48, lower 4 digits
Target value #48, upper 4digits
Subroutine number
S+143
S+144
(BCD 8 digits) F8388608
to 08388607
((Incremental) 0000 to 0255
(Decrement) F000 to F255
Lower word of target value 48
Upper word of target value 48
Interrupt task number for target value 48
(BIN 8 digits) 80000000
to 7FFFFFFF
(Incremental) 0000 to 00FF
(Decrement) 8000 to 80FF
S
S+1
S+2
S+3
S+142
S+143
S+144
Ring mode
S+2
S+3
Number of target values
Target value #1, lower 4digits
Target value #1, upper 4digits
Subroutine number
S+4
S+5
(BCD 4 digits) 0001 to 0048
(BCD 8 digits) 00000000
to 00064999
(Incremental) 0000 to 0255
(Decrement) F000 to F255
CQM1H
S+144
Target value #48, lower 4digits
Target value #48, upper 4digits
Subroutine number
S+145
S+146
(BCD 8digits 00000000
to 00064999
(Incremental) 0000 to 0255
(Decrement) F000 to F255
S
S+1
Ring value, lower 4 digits
Ring value, upper 4 digits
(BCD 8digits 00000000
to 00065000
Number of target values
Lower word of target value 1
Upper word of target value 1
interrupt task number for target value
(BIN 4 digits) 0001 to 0030Hex
(BIN 8 digits) 80000000
to 7FFFFFFF
(Incremental) 0000 to 00FF
(Decrement) 8000 to 80FF
CJ1M/CJ2M
Lower word of target value 48
Upper word of target value 48
Interrupt task number for target value
(BIN 8 digits) 80000000
to 7FFFFFFF
(Incremental) 0000 to 00FF
(Decrement) 8000 to 80FF
S
S+1
S+2
S+3
S+142
S+143
S+144
Ring value:
