Omron CQM1H User Manual

Unit CQM1H CJ2M
CQM1-OC221 CJ1W-OC201
Terminal block/250VAC 24VDC 2A/8 points
Independent common
Terminal block/250VAC 24VDC 2A/8points
Independent common
CQM1-OC222 CJ1W-OC211
Terminal block/250VAC 24VAC 2A/16
points
Terminal block/250VAC 24VDC 2A/16
points
CQM1-OC224 CJ1W-OC201
Relay output units
Terminal block/250VAC 24VDC 2A/8 points
Independent common
Terminal block 250VAC 24VDC 2A/8
points
Independent common
CQM1-OA221 CJ1W-OA201
Terminal block/100 to 240VAC
0.4A/8 points
Terminal block/250VAC 0.6A/8 points
CQM1-OA222 CJ1W-OA201
Triac output units
Terminal block/100 to 240VAC
0.4A/6 points
Terminal block/250VAC 0.6A/8 points
CQM1-OD211 CJ1W-OD201
Terminal block/24VDC 2A/ 8 points Terminal block 12 to 24VDC 2A 8 points
CQM1-OD212 None
Terminal block/4.5VDC 50mA to
26.4VDC 300mA/16 points
－
CQM1-OD213 None
Connector/4.5VDC 16mA to 26.4VDC
100mA/32 points
-
CQM1-OD216 CJ1W-OD232
Connector/24VDC 500mA Sourcing type/32
points
Connector/24VDC 0.5A/ 32 points
Load short-circuit protection
CQM1-OD214 CJ1W-OD212
Terminal block/24VDC 300mASourcing
type/16 points
Terminal block/24VDC 0.5A/16 points
Load short-circuit protection
CQM1-OD215 CJ1W-OD202
Transistor Output
Units
Terminal block/24VDC 1.0ASourcing type/8
points
Short-circuit protection
Terminal block/24VDC 2A/8 points
Load short-circuit protection and
disconnected line detection
♦Special I/O Unit
Unit CQM1H CJ2M
CQM1-B7A12 CJ1W-B7A14
16 inputs 64 inputs
CQM1-B7A13 CJ1W-B7A14
32 inputs 64 inputs
CQM1-B7A02 CJ1W-B7A04
16 outputs 64 outputs
CQM1-B7A03 CJ1W-B7A04
32 outputs 64 outputs
CQM1-B7A21 None
B7A Interface
Units
16 inputs/16 outputs -
CQM1-AD041 CJ1W-AD041-V1 Analog input units
4 analog inputs
-10 to +10 V, 0 to 10 V, 1 to 5 V, 4 to
20 mA
4 analog inputs
0 to 5V, -10 to+10 V, 0 to 10 V, 1 to 5 V, 4 to
20 mA
CQM1-DA021
CJ1W-DＡ021
Analog output
units
2 analog outputs
-10 to+10 V, 0 to 20 mA
2 analog outputs
1 to 5V, 4 to 20 mA, 0 to 5 V,-10 to+10 V, 0 to
10 V
6

Omron CQM1H Specifications

General

Model	CQM1H
Type	Modular PLC
Programming Language	Ladder logic
Operating Temperature	0 to 55°C
Storage Temperature	-20 to 75°C
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude
I/O Capacity	Up to 512 points
Communication Ports	RS-232C
Power Supply	24 VDC
Mounting	DIN rail
Instruction Execution Time	0.1 μs per instruction
Humidity	10% to 90% RH (non-condensing)
Shock Resistance	147 m/s²
Expansion	Supports expansion modules
