CS/CJ Series HOST Link Driver
GP-Pro EX Device/PLC Connection Manual
14
Setting of External Device
For communication settings of INNER board, open [I/O Table] of the ladder software first. Then, select [INNER
Board Soft Switch] from the menu displayed by right-clicking [CS**-CPU**] (CPU of the External Device to
set) and set as below.
Notes
• Do not set the duplicate node address in the same network address group.
Setup Items Settings
Line Speed 19200
Parameter 1,7,2,E
Mode Default (HOST Link)
Send Delay Time 0
CS Control None
Unit No. Option
Source Network Address
*1
*1 Parameter used when you access beyond network. Set in the routing table of "CX-Net Network Configuration".
Please refer to the manual of the External Device for more details.
Option
Node Address Setting Rotary Switch
*2
*2 Parameter used when you access beyond network. Set with the rotary switch on the front of the Controller Link
unit used for access beyond network.
Option
To Next Page
