CS/CJ Series HOST Link Driver
GP-Pro EX Device/PLC Connection Manual
17
Setting of External Device
For communication settings of INNER board, open [I/O Table] of the ladder software first. Then, select [INNER
Board Soft Switch] from the menu displayed by right-clicking [CS**-CPU**] (CPU of the External Device to
set) and set as below.
Notes
• Do not set the duplicate node address in the same network address group.
Setup Items Settings
WIRE (2wire/4wire switch)
*1
*1 Use the WIRE switch on the front of the INNER board to set.
4wire
TERM (Termination resistance switch)
*2
*2 Use the TERM switch on the front of the INNER board to set. For 1:n connection, set only the station that serves
as termination resistance to ON.
ON
Line Speed 19200
Parameter 1,7,2,E
Mode Default (HOST Link)
Send Delay Time 0
CS Control None
Unit No. Option
Source Network Address
*3
*3 Parameter used when you access beyond network. Set in the routing table of "CX-Net Network Configuration".
Please refer to the manual of the External Device for more details.
Option
Node Address Setting Rotary Switch
*4
*4 Parameter used when you access beyond network. Set with the rotary switch on the front of the Controller Link
unit used for access beyond network.
Option
To Next Page
