Omron D4N Series User Manual

D4N
List of Recommended Substitute Products
: The actuator on the D4D-N is a non-safety type. The D4N is recommended for safety applications (form lock type). Be sure to mount it
correctly.
: M screws are recommended to comply with European standards. Therefore, the M20 type is recommended as a substitute when the Pg13.5
conduit-type is not available in a D4N model.
Safety Limit Switches
Discontinued
product
Recommended
substitute product
Discontinued
product
Recommended
substitute product
Discontinued
product
Recommended
substitute product
D4D-1120N D4N-1120 D4D-1520N D4N-1A20 D4D-1A20N D4N-1B20
D4D-2120N D4N-2120 D4D-2520N D4N-2A20 D4D-2A20N D4N-2B20
D4D-3120N D4N-3120 D4D-3520N D4N-3A20 D4D-3A20N D4N-3B20
D4D-5120N D4N-5120 D4D-5520N D4N-5A20 D4D-5A20N D4N-5B20
D4D-6120N D4N-6120 D4D-6520N D4N-6A20 D4D-6A20N D4N-6B20
D4D-1122N D4N-1122 D4D-1522N D4N-1A22 D4D-1A22N D4N-1B22
D4D-2122N D4N-2122 D4D-2522N D4N-2A22 D4D-2A22N D4N-2B22
D4D-3122N D4N-3122 D4D-3522N D4N-3A22 D4D-3A22N D4N-3B22
D4D-5122N D4N-5122 D4D-5522N D4N-5A22 D4D-5A22N D4N-5B22
D4D-6122N D4N-6122 D4D-6522N D4N-6A22 D4D-6A22N D4N-6B22
D4D-1125N D4N-1125 D4D-1525N D4N-1A25 D4D-1A25N D4N-1B25
D4D-2125N D4N-2125 D4D-2525N D4N-2A25 D4D-2A25N D4N-2B25
D4D-3125N D4N-3125 D4D-3525N D4N-3A25 D4D-3A25N D4N-3B25
D4D-1131N D4N-1131 D4D-1531N D4N-1A31 D4D-1A31N D4N-1B31
D4D-2131N D4N-2131 D4D-2531N D4N-2A31 D4D-2A31N D4N-2B31
D4D-3131N D4N-3131 D4D-3531N D4N-3A31 D4D-3A31N D4N-3B31
D4D-5131N D4N-5131 D4D-5531N D4N-5A31 D4D-5A31N D4N-5B31
D4D-6131N D4N-6131 D4D-6531N D4N-6A31 D4D-6A31N D4N-6B31
D4D-1132N D4N-1132 D4D-1532N D4N-1A32 D4D-1A32N D4N-1B32
D4D-2132N D4N-2132 D4D-2532N D4N-2A32 D4D-2A32N D4N-2B32
D4D-3132N D4N-3132 D4D-3532N D4N-3A32 D4D-3A32N D4N-3B32
D4D-5132N D4N-5132 D4D-5532N D4N-5A32 D4D-5A32N D4N-5B32
D4D-6132N D4N-6132 D4D-6532N D4N-6A32 D4D-6A32N D4N-6B32
D4D-1162N D4N-1162 D4D-1562N D4N-1A62 D4D-1A62N D4N-1B62
D4D-2162N D4N-2162 D4D-2562N D4N-2A62 D4D-2A62N D4N-2B62
D4D-3162N D4N-3162 D4D-3562N D4N-3A62 D4D-3A62N D4N-3B62
D4D-5162N D4N-5162 D4D-5562N D4N-5A62 D4D-5A62N D4N-5B62
D4D-6162N D4N-6162 D4D-6562N D4N-6A62 D4D-6A62N D4N-6B62
D4D-1172N D4N-1172 D4D-1572N D4N-1A72 D4D-1A72N D4N-1B72
D4D-2172N D4N-2172 D4D-2572N D4N-2A72 D4D-2A72N D4N-2B72
D4D-3172N D4N-3172 D4D-3572N D4N-3A72 D4D-3A72N D4N-3B72
D4D-5172N D4N-5172 D4D-5572N D4N-5A72 D4D-5A72N D4N-5B72
D4D-6172N D4N-6172 D4D-6572N D4N-6A72 D4D-6A72N D4N-6B72
D4D-112HN D4N-112H D4D-152HN D4N-1A2H D4D-1A2HN D4N-1B2H
D4D-212HN D4N-212H D4D-252HN D4N-2A2H D4D-2A2HN D4N-2B2H
D4D-312HN D4N-312H D4D-352HN D4N-3A2H D4D-3A2HN D4N-3B2H
http://www.ia.omron.com/
22
(c)Copyright OMRON Corporation 2007 All Rights Reserved.

Omron D4N Series Specifications

General

Voltage Rating	250 VAC, 30 VDC
Ingress Protection	IP67
Actuator Type	Plunger
Current Rating	10 A
Housing Material	Plastic
Category	Switch
Connection Method	Screw terminals
Operating Speed	0.05 mm/s to 0.5 m/s
Standards	UL 508
Mechanical Life	15, 000, 000 operations minimum
Electrical Life	500, 000 operations
Contact Configuration	1NC/1NO, 2NC
