Omron E3C-LD11 User Manual

17
E3NC
Dimensions
Sensor Heads
(Unit: mm)
Tolerance class IT16 applies to dimensions in this data sheet unless otherwise specified.
Mounting Holes
Vinyl-insulated Robot cable
Two, 2.3-dia., 6 conductors
(Conductor cross-section: 0.08 mm
2
, Insulation diameter: 0.38 mm),
Standard cable length: 2 m, Minimum bending radius: 12 mm
6
Emission and
reception axis
6.2
3
2.9
OUT indicator
STABILITY indicator
12.412.4
3636
2525
12
21.5
27.5
10
23.5 9.5
6.6
Two, 3.2 dia.
(mounting holes)
Emission and
reception center
1.2
10
9.5
±0.1
17
±0.1
17
20
18
Connector
Two, M3 holes
Ferrite core *1
25
12.8
11.2
90
±10
*1 A ferrite core is attached to the Sensor
Head end of the cable attached to the
E3NC-LH03 5M.
*2
*2 A blue ID tube is attached.
Retro-reflective Model
E3NC-LH03
Diffuse-reflective Model
E3NC-LH02
18
6
5.5
28.928.9
3333
9.9 16
27
3
15
27
±0.05
16
±0.05
8.5
11.5
3
10
12.2
12.3
18.5
3
3.5
11
6.2
3.6
8
12.412.4
Two, 3.2 dia.
(mounting holes)
(Adjuster locked: 32.4,
Unlocked: 33.7)
9 dia.
*
Two, M3 holes
Mounting Holes
Connector
Vinyl-insulated Robot cable
Two, 2.3-dia., 6 conductors
(Conductor cross-section: 0.08 mm
2
, Insulation diameter: 0.38 mm),
Standard cable length: 2 m, Minimum bending radius: 12 mm
OUT indicator
Adjuster
STABILITY indicator
Emission axis
Reception center
Emission center
* A blue ID tube is attached.
