Omron E3Z series

A-65E3Z
E3Z
Retroreflective Models
Pre-wired
E3Z-B61
E3Z-B62
E3Z-B81
E3Z-B82
E3Z-R61
E3Z-R81
Diffuse-reflective
Pre-wired
E3Z-D61
E3Z-D81
E3Z-D62
E3Z-D82
E3Z-L61
E3Z-L81
M12 x 1
1
3
2
4
Vinyl-insulated round cable
with three conductors, 4 dia.;
standard length: 0.3 m
Terminal No. Specifications
1+V
2 ---
30V
4 Output
Note: Terminal 2 is not used.
Connector relay models
(E3Z-###-M1J)
20
12.45
8.8
3.2
Stability indicator (green)
Operation indicator (orange)
17
2.1
25.4
Vinyl-insulated round cable with three conductors, 4 dia.
(0.2 mm
² with 1.1-dia. insulator); standard length: 2 m
2-M3
31
15.5
Two, 7-dia.
lenses
Receiver
Optical axis
Emitter
4
18
4
10.410.8
4.3
Sensing adjuster
Operation selector
B is a free terminal.
Termi-
nal No.
Specifica-
tions
1+V
2---
30V
4 Output
Retroreflective Models
Connector type
E3Z-B66
E3Z-B67
E3Z-B86
E3Z-B87
E3Z-R66
E3Z-R86
Diffuse-reflective
Connector type
E3Z-D66
E3Z-D86
E3Z-D67
E3Z-D87
E3Z-L66
E3Z-L86
20
12.45
8.8
3.2
Stability indicator (green)
Operation indicator (orange)
17
2.1
25.4
M8 connector
31
10.4
15.5
Two, 7-dia.
lenses
Receiver
Optical axis
Emitter
4
18
4
10.410.8
4.3
Sensing adjuster
Operation selector
9.75
2-M3
Distance-settable Models
Pre-wired models
E3Z-LS61
E3Z-LS81
4.3
8
12.7
20
10.8 10.4
17
3118 4
4
25.4
2.1
13.5
Operation indicator
(orange)
Operation selector
Set distance adjuster
Stability indicator (green)
2 lenses (7 dia.)
Receiver
Optical axis
Emitter Two, M3
4-dia, 4-core vinyl-insulated round cable
(conductor cross-sectional area: 0.2 mm²;
insulation diameter: 1.1 mm)
Standard length: 2 m / 0.5 m
