3 - 9
3 Communications Data for CompoWay/F
E5C-T Digital Temperature Controllers Programmable Type Communications Manual (H186)
3-1 Variable Area (Setting Range) List
3
C3 (83) 0007 PID ON/OFF H'00000000 (0): ON/OFF
H'00000001 (1): 2 PID control
Initial
setting
C3 (83) 0008 Standard or
Heating/Cooling
H'00000000 (0): Standard
H'00000001 (1): Heating and cooling
C3 (83) 000A Control Period
(Heating)
H'FFFFFFFE (−2): 0.1 s
H'FFFFFFFF (−1): 0.2 s
H'00000000 (0): 0.5 s
H'00000001 to H'00000063 (1 to 99)
C3 (83) 000B Control Period
(Cooling)
H'FFFFFFFE (−2): 0.1 s
H'FFFFFFFF (−1): 0.2 s
H'00000000 (0): 0.5 s
H'00000001 to H'00000063 (1 to 99)
C3 (83) 000C Direct/Reverse
Operation
H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
C3 (83) 000D Alarm 1 Type H'00000000 (0): Alarm function OFF
H'00000001 (1): Upper and lower-limit alarm
H'00000002 (2): Upper-limit alarm
H'00000003 (3): Lower-limit alarm
H'00000004 (4): Upper and lower-limit range alarm
H'00000005 (5): Upper and lower-limit alarm with
standby sequence
H'00000006 (6): Upper-limit alarm with standby
sequence
H'00000007 (7): Lower-limit alarm with standby
sequence
H'00000008 (8): Absolute-value upper-limit alarm
H'00000009 (9): Absolute-value lower-limit alarm
H'0000000A (10): Absolute-value upper-limit alarm with
standby sequence
H'0000000B (11): Absolute-value lower-limit alarm with
standby sequence
H'0000000C (12): LBA (Loop Burnout Alarm)
H'0000000D (13): PV change rate alarm
H'0000000E (14): SP absolute-value upper-limit alarm
H'0000000F (15): SP absolute-value lower-limit alarm
H'00000010 (16): MV absolute-value upper-limit alarm
H'00000011 (17): MV absolute-value lower-limit alarm
C3 (83) 000E Alarm 2 Type H'00000000 to H'00000011 (0 to 17)
Note: Same settings as the Alarm 1 Type. However, the
LBA (loop burnout alarm) cannot be set.
C3 (83) 000F Alarm 3 Type H'00000000 to H'00000011 (0 to 17)
Note: Same settings as the Alarm 1 Type. However, the
LBA (loop burnout alarm) cannot be set.
Variable
type
Address
Parameter
name
Setting (monitor) value Level
To Next Page
