Omron E5 K Series User Manual

E5AK/E5CK/E5EK
E5AK/E5CK/E5EK
116
 E5CK-302
The E5CK-302 model has the same dimension and cutouts as the E5CK.
 ACCESSORIES (Order Separately)
E53-COV0809 E53-COV08
Terminal Cover for E5AK
Terminal Cover for E5EK
43.2 (1.70)
89 (3.50)
1.5
89 (3.50)
22.05
(0.87)
89 (3.50)
43.2 (1.70)
3
33
1.5 3
Terminal Cover for E5CK
44.3
(1.74)
44.3
(1.74)
E53-COV07
Current Transformer (E5AK and E5EK only for Heater Burnout Alarm)
E54-CT1 E54-CT3
5.8 dia.
(0.23)
12 dia.
(0.47)
2.36 dia.
Two, M3 (depth: 4)
40 (1.57)
x 40 (1.57)
30
(1.18)
15
30
(1.18)
21 (0.83)
15 (0.59)
25
(0.98)
10
(0.39)
30 (1.18)
40 (1.57)
2.8
(0.11)
7.5 (0.30)
3
(0.12)
