 OPTIONAL OUTPUT BOARDS
Description Specifications Compatible controller Max. quantity Part number
Relay SPST, 5 A, 250 VAC E5AK/E5EK 2 E53-R
SSR (solid state relay) 1 A, 75 to 250 VAC E5AK/E5EK 2 E53-S
Voltage pulse
NPN, 12 VDC E5AK/E5EK 2 E53-Q
NPN, 24 VDC E5AK/E5EK 2 E53-Q3
PNP, 24 VDC E5AK/E5EK 2 E53-Q4
Linear current
4 to 20 mA E5AK/E5EK 2 E53-C3
0 to 20 mA E5AK/E5EK 2 E53-C3D
Linear voltage
0 to 10 VDC E5AK/E5EK 2 E53-V34
0 to 5 VDC E5AK/E5EK 2 E53-V35
Relay/Relay SPST/SPST, 5 A, 250 VAC E5CK 1 E53-R4R4
Relay/Pulse
SPST, 5 A/NPN, 24 VDC E5CK 1 E53-Q4R4
SPST, 5 A/PNP, 24 VDC E5CK 1 E53-Q4HR4
Relay/Linear current
SPST, 5 A/4 to 20 mA E5CK 1 E53-C4R4
SPST, 5 A/0 to 20 mA E5CK 1 E53-C4DR4
Relay/Linear voltage SPST, 5 A/0 to 10 VDC E5CK 1 E53-V44R4
Pulse/Pulse
NPN/NPN, 24 VDC E5CK 1 E53-Q4Q4
PNP/PNP, 24 VDC E5CK 1 E53-Q4HQ4H
Computer communications
RS-232C E5AK/E5EK 3/1 E53-AK01
RS-232C E5CK 1 E53-CK01
RS-422 E5AK/E5EK 3/1 E53-AK02
Computer communications RS-485
E5AK/E5EK 3/1 E53-AK03
E5CK 1 E53-CK03
Event input
For remote set point E5AK/E5EK 3/1 E53-AKB
For remote set point E5CK 1 E53-CKB
Transfer output
4 to 20 mA E5AK/E5EK 3/1 E53-AKF
4 to 20 mA E5CK 1 E53-CKF
Note: If the control period is less than 5 seconds, use an SSR (solid state relay) or pulse voltage output.
