Omron E5EN-H User Manual

12 Advanced Digital Temperature Controller E5AN-H/E5EN-H
Nomenclature
Dimensions (Unit: mm)
PF
A/M
SUB3
HA
SUB2
OUT2
OUT1
CMW
RSP
STOP
MANU
SUB1
MV
SV
PV
Ir
E5AN-H
Operation indicators
No.1 display
No.2 display
No.3 display
Up Key
Down Key
Temperature unit
Mode KeyLevel Key
Programmable
Function Key/
Auto/Manual Key
E5AN-H E5EN-H
Ir
PF
A/M
MV
SV
PV
SUB2
SUB3
STOPOUT1
RSP
MANU CMWOUT2
SUB1
HA
E5EN-H
Operation indicators
Temperature unit
Operation indicators
Mode Key
Level Key
No.1 display
No.2 display
No.3 display
Up Key
Down Key
Programmable
Function Key/
Auto/Manual Key
Mounting Bracket
(Accessory)
Waterproof
Packing
(Accessory)
Terminal Cover
(E53-COV16)
(Accessory)
Crimp terminal size: M3.5
96 × 96 112 91
79.2
6
2
92
+0.8
0
92
+0.8
0
92
+0.8
0
(96 × number of units − 3.5)
+1.0
0
120 min.
Group mounting does not
allow waterproofing.
Mounted Separately
Group Mounted✽
• Recommended panel thickness is 1 to
8mm.
• Group mounting is not possible in the
vertical direction. (Maintain the specified
mounting space between Controllers.)
• To mount the Controller so that it is
waterproof, insert the waterproof packing
onto the Controller.
• When two or more Controllers are
mounted, make sure that the surrounding
temperature does not exceed the
allowable operating temperature specified
in the specifications.
E5AN-H
✽ Group mounting is not possible if an SSR output is used for
control output 1 or 2 and the E53-C3N or E53-C3DN Output Unit
is used. For these combinations, maintain the following mounting
space between Controllers.
92
+0.8
0
92
+0.8
0
110 min.
120 min.
