Alarm Delays Section 4-10
Note (1) The defaults are 0, i.e., the ON and OFF delays are disabled.
(2) The parameters are displayed when alarm outputs are assigned and
when the alarm type is set to any type but 0 (none).
Operating Procedure Use the following procedure to set ON and OFF delays for the alarm 1 output.
An ON delay of 5 seconds and an OFF delay of 10 s will be set.
Operation Level
Initial Setting Level
1. Press the O key for at least three seconds to move from the operation
level to the initial setting level.
Initial Setting Level
2. Select the “move to advanced function setting level” parameter by press-
ing the M key.
Advanced Function Setting Level
3. Press the D key to enter the password (−169) and move from the initial
setting level to the advanced function setting level.
Advanced Function Setting Level
4. Press the M key to select the “alarm 1 ON delay” parameter.
5. Press the U key to set the parameter to 5.
Advanced Function Setting Level
6. Press the M key to select the “alarm 1 OFF delay” parameter.
7. Press the U key to set the parameter to 10.
Initial Setting Level
8. Press the O key for at least one second to move from the advanced func-
tion setting level to the initial setting level.
Operation Level
9. Press the O key for at least one second to move from the initial setting
level to the operation level.
C
25
100
PV/SP
in-t
5
Input type
amov
0
Move to ad-
vanced function
setting level
init
off
Parameter
initialization
a1on
0
Alarm 1 ON
delay
a1on
5
a1of
0
Alarm 1 OFF
delay
a1of
10
in-t
5
Input type
C
25
100
PV/SP
