Initial Setting Level Section 5-6
Related Parameters
Temperature unit: Page 121, SP upper limit, SP lower limit: Page 122 (initial
setting level)
Input type Specifications Set value Input temperature range
Controllers
with Ther-
mocouple/
Resistance
Thermome-
ter Univer-
sal-inputs
Platinum resistance
thermometer
Pt100 0 −200 to 850 (°C)/−300 to 1500 (°F)
1 −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F)
2 0.0 to 100.0 (°C)/0.0 to 210.0 (°F)
JPt100 3 −199.9 to 500.0 (°C)/−199.9 to 900.0 (°F)
4 0.0 to 100.0 (°C)/0.0 to 210.0 (°F)
Thermocouple K
5 −200 to 1300 (°C)/−300 to 2300 (°F)
6 −20.0 to 500.0 (°C)/0.0 to 900.0 (°F)
J7−100 to 850 (°C)/−100 to 1500 (°F)
8 −20.0 to 400.0 (°C)/0.0 to 750.0 (°F)
T9−200 to 400 (°C)/−300 to 700 (°F)
10 −199.9 to 400.0 (°C)/−199.9 to 700.0 (°F)
E 11 0 to 600 (°C)/0 to 1100 (°F)
L12−100 to 850 (°C)/−100 to 1500 (°F)
U13−200 to 400 (°C)/−300 to 700 (°F)
14 −199.9 to 400.0 (°C)/−199.9 to 700.0 (°F)
N15−200 to 1300 (°C)/−300 to 2300 (°F)
R 16 0 to 1700 (°C)/0 to 3000 (°F)
S 17 0 to 1700 (°C)/0 to 3000 (°F)
B 18 100 to 1800 (°C)/300 to 3200 (°F)
Infrared Tempera-
ture Sensor
ES1B
10 to 70 (°C) 19 0 to 90 (°C)/0 to 190 (°F)
60 to 120 (°C) 20 0 to 120 (°C)/0 to 240 (°F)
115 to 165 (°C) 21 0 to 165 (°C)/0 to 320 (°F)
140 to 260 (°C) 22 0 to 260 (°C)/0 to 500 (°F)
Analog input 0 to 50 mV 23 One of the following ranges depending on the scal-
ing.
−1999 to 9999
−199.9 to 999.9
Input type Specifications Set value Input temperature range
Controllers
with Ana-
log Inputs
Current input 4 to 20 mA
0 One of the following ranges depending on the scal-
ing.
−1999 to 9999
−199.9 to 999.9
−19.99 to 99.99
−1.999 to 9.999
0 to 20 mA 1
Voltage input 1 to 5 V 2
0 to 5 V 3
0 to 10 V 4
See
See
■
