Omron E5EZ User Manual

xvii
Control
output 1
Relay E5CZ-R@@@
SPST-NO, 250 VAC, 3 A (resistive load)
Electrical life: 100,000 operations.
E5CZ-R@@@@
SPST-NO, 250 VAC, 3 A (resistive load)
Electrical life: 100,000 operations.
(No models with plug-in type) E5CZ-R@@@U
SPDT, 250 VAC, 3 A (resistive load)
Electrical life: 100,000 operations.
E5AZ-R@@@
SPST-NO, 250 VAC, 5 A (resistive load)
Electrical life: 100,000 operations.
E5AZ-R@@@@@
SPST-NO, 250 VAC, 5 A (resistive load)
Electrical life: 100,000 operations.
E5EZ-R@@@
SPST-NO, 250 VAC, 5 A (resistive load)
Electrical life: 100,000 operations.
E5EZ-R@@@@@
SPST-NO, 250 VAC, 5 A (resistive load)
Electrical life: 100,000 operations.
Voltage E5CZ-Q@@@
12 VDC ±15% (PNP)
Max. load current: 21 mA
With short-circuit protection
E5CZ-Q@@@@
12 VDC ±15% (PNP)
Max. load current: 21 mA
With short-circuit protection
(No models with plug-in type) E5CZ-Q@@@U
12 VDC ±15% (PNP)
Max. load current: 21 mA
With short-circuit protection
E5AZ-Q@@@
12 VDC +15%/−20% (PNP)
Max. load current: 40 mA
With short-circuit protection
E5AZ-Q@@@@@
12 VDC +15%/−20% (PNP)
Max. load current: 40 mA
With short-circuit protection
E5EZ-Q@@@
12 VDC +15%/−20% (PNP)
Max. load current: 40 mA
With short-circuit protection
E5EZ-Q@@@@@
12 VDC +15%/−20% (PNP)
Max. load current: 40 mA
With short-circuit protection
Current E5CZ-C@@@
4 to 20 mA DC
Load: 600 Ω max.
Resolution: Approx. 2,600
E5CZ-C@@@@
4 to 20 mA DC,0 to 20 mA DC.
Load: 600 Ω max.
Resolution: Approx. 2,700
E5AZ-C@@@
4 to
20 mA DC
Load: 600 Ω max.
Resolution: Approx. 2,600
E5AZ-C@@@@
4 to 20 mA DC,0 to 20 mA DC.
Load: 600 Ω max.
Resolution: Approx. 2,700
E5EZ-C@@@
4 to 20 mA DC
Load: 600 Ω max.
Resolution: Approx. 2,600
E5EZ-C@@@@
4 to 20 mA DC,0 to 20 mA DC.
Load: 600 Ω max.
Resolution: Approx. 2,700
Display
method
E5CZ/CZ-U 7-segment digital display and single-LED
indicators
11-segment digital display and single-LED indica-
tor (Improved visibility)
(A 7-segment digital display also possible.)
E5AZ/EZ 7-segment digital display and single-LED
indicators
11-segment digital display and single-LED indica-
tor (Improved visibility)
(A 7-segment digital display also possible.)
Transfer output (No models with transfer outputs) E5@Z-C@@@@
Allocated to current output
4 to 20 mA DC,0 to 20 mA DC.
Load: 600 Ω max.
Resolution: Approx. 2,700 (4 to 20 mA DC)
Item Previous models Improved models
