Omron E5EZ User Manual
5
of 1
of 1 rating
208 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
14
Communications Function
Section 1-4
Communications
baud rate
bps
1.2, 2.4, 4.8, 9.6, 19.2, 38.4
1.2
,
2.4
,
4.8
,
9.6
,
19.2
,
38.4
9.6
kbps
Communications
data length
len
7, 8
7
Bits
Communications
stop bits
sbit
1, 2
2
Bits
Communications
parity
prty
None, Even, Od
d
none
,
even
,
odd
Even
None
Send data wait time
sdwe
0 to 99
20
ms
Parameter
Symbol
Setting (m
onitor) value
Selection sy
mbols
Default
U
nit
36
38
Table of Contents
Table of Contents
20
Default Chapter
7
Safety Precautions
7
Precautions for Operation
13
Communications Specifications
17
Other Functions
17
Conventions Used in this Manual
18
About this Manual
22
Introduction
24
Names of Parts
25
Front Panel
25
Meanings of Indicators
26
Using the Keys
27
I/O Configuration and Main Functions
28
Main Functions
31
Setting Level Configuration and Key Operations
33
Selecting Parameters
35
Fixing Settings
35
Communications Function
36
Preparations
38
Installation
39
Panel Cutout
40
Wiring Terminals
44
Precautions When Wiring
45
Using the Support Software Port
50
Section Section 3 Basic Operation
54
Basic Operation
54
Initial Setting Examples
55
Setting the Input Type
57
Input Type
57
Selecting the Temperature Unit
59
Selecting PID Control or ON/OFF Control
59
Setting Output Specifications
59
Temperature Unit
59
Control Periods
59
Direct and Reverse Operation
60
Assigned Output Functions
61
Setting the Set Point (SP)
63
Using ON/OFF Control
63
Changing the SP
63
ON/OFF Control
63
Settings
64
Determining PID Constants (AT, ST, Manual Setup)
66
AT (Auto-Tuning)
66
ST (Self-Tuning)
67
St Stable Range
68
Manual Setup
69
Alarm Outputs
70
Alarm Types
70
Alarm Values
72
Using HB and HS Alarms
73
HB and HS Alarm Operations
73
Installing Current Transformers (CT)
74
Calculating Detection Current Values
74
Application Examples
75
Settings (HB Alarm)
76
Settings (HS Alarm)
77
Section 4 Applications Operations
80
Applications Operations
80
Shifting Input Values
82
Shifting Inputs
82
How to Calculate Input Shift Values for a 2-Point Shift
83
Alarm Hysteresis
86
Standby Sequence
86
Alarm Latch
86
Close in Alarm/Open in Alarm
87
Setting Scaling Upper and Lower Limits for Analog Inputs
88
Analog Input
88
Executing Heating/Cooling Control
89
Heating/Cooling Control
89
Settings
91
Using Event Inputs
92
Event Input Settings
92
How to Use the Multi-SP Function
92
Settings
94
Executing Run/Stop Control
95
Switching between Auto and Manual Control
95
Setting the SP Upper and Lower Limit Values
96
Set Point Limiter
96
Setting
96
Using the SP Ramp Function to Limit the SP Change Rate
97
SP Ramp
97
Moving to the Advanced Function Setting Level
99
Using the Key Protect Level
100
Protection
100
Alarm Delays
102
Loop Break Alarm
104
Loop Break Alarm (LBA)
104
Performing Manual Control
107
Manual Operation
107
Using the Transfer Output
111
Transfer Output Function
111
Output Adjustment Functions
114
Output Limits
114
Parameters
116
Conventions Used in this Section
117
Meanings of Icons Used in this Section
117
About Related Parameter Displays
117
Protect Level
118
Operation Level
120
Process Value
121
Adjustment Level
129
Manual Control Level
140
Initial Setting Level
141
Advanced Function Setting Level
152
Communications Setting Level
172
Appendix A
174
Specifications
176
Error Displays
179
Troubleshooting
181
Parameter Operation Lists
186
Setting Levels Diagram
197
Parameter Flow
198
Index
200
Revision History
206
Other manuals for Omron E5EZ
Manual
56 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Omron E5EZ and is the answer not in the manual?
Ask a question
Omron E5EZ Specifications
General
Brand
Omron
Model
E5EZ
Category
Temperature Controller
Language
English
Related product manuals
Omron E5EC
440 pages
Omron E5EWL
2 pages
Omron E5EX–H
16 pages
Omron E5CZ
208 pages
Omron E5CC
440 pages
Omron E5CB
2 pages
Omron E5AN
355 pages
Omron E5CN
320 pages
Omron E5DC
440 pages
Omron E5AC
440 pages
Omron E5CSV
110 pages
Omron E5CWL
14 pages
