Setting Output Specifications Section 3-5
Initial Setting Level
3. Press the U key to set the parameter to h-c.
Note The following output assignments do not need to be set because they
are set automatically by changing the control mode, but they are
shown here as a reference for checking the assignments for each out-
put.
4. Select the “move to advanced function setting level” parameter by press-
ing the M key.
Advanced Function Setting Level
5. Press the D key to enter the password (“−169”), and move from the initial
setting level to the advanced function setting level.
Advanced Function Setting Level
6. Select the “alarm output 1 assignment” parameter by pressing the M
key.
7. Press the U or D key to set o.
(The default is o.)
Advanced Function Setting Level
8. Select the “alarm output 1 assignment” parameter by pressing the M
key.
9. Press the U or D key to set alm1.
(The default is alm1.)
Advanced Function Setting Level
E5CZ
E5AZ/EZ
10. Select the “alarm output 2 assignment” parameter by pressing the M
key.
(The default of the E5CZ is c-o.)
(The default of the E5AZ/EZ is alm2.)
11. Press the U or D key to set c-o.
Initial Setting Level
12. Press the O key for at least one second to move from the advanced func-
tion setting level to the initial setting level.
5-hc
h-c
amov
0
Move to ad-
vanced function
setting level
init
off
Parameter
initialization
out1
o
Control output 1
assignment
out1
o
alm1
alm1
Alarm output 1
assignment
alm1
alm1
alm2
c-o
Alarm output 2
assignment
alm2
alm2
alm2
c-o
in-t
5
Input type
