Omron F3SJ-E N25 Series - Basic Type (Muting System)

17
F3SJ-E/B
User’s Manual
Chapter2 Wiring Diagrams
System Configuration and Functions
E
 Basic Type (Muting System)
 Minimum wiring required to operate the F3SJ-B
(Wiring for auto reset mode)
 Wiring for muting function
0V
Power
supply
+24 VDC
Emitter
Receiver
(Gray) Communication line (+)
(Pink)
Communication line (-)
Open
Open
Open Open
Open
Open
Open Open
Open
24 V (Brown)
External device monitoring input (Red)
0 V (Blue)
Auxiliary output (Yellow)
Safety output 1 (Black)
Safety output 2 (White)
Shield
Shield
0 V (Blue)
Muting input 1 (white)
Muting input 2 (Red)
Test input (Black)
Reset input (Yellow)
24 V (Brown)
F39-JDA-L F39-JDA-D
24 V (Brown)
External device monitoring input (Red)
*2
0 V (Blue)
Auxiliary output (Yellow)
Safety output 1 (Black)
Safety output 2 (White)
Shield
Test input (Black)
*1
Reset input (Yellow)
*1
24 V (Brown)
Shield
0 V (Blue)
(Gray) Communication line (+)
(Pink)
Communication line (-)
S1
S2
A1
B1
KM1, KM2
K1
: External test switch
(connect to 24 V if a switch is not required)
: Lockout reset switch (connect to 0 V if a switch is not required)
: Contact by muting sensor A1
: Contact by muting sensor B1
: Safety relay with force-guided contact (G7SA) or magnetic contactor
:
Indicator or PLC, etc. (for monitoring)
S1
B1 A1
S2
K1 KM1 KM2
0 V
Emitter
Receiver
Muting input 1 (white)
Muting input 2 (Red)
Power
supply
+24 VDC
*1.
Used as override input as well.
*2.
When muting system is used, connect it to +24 V as the external device monitoring function cannot be used.
*3. Use a switch for small loads (input specifications: 24 V, 1.0 mA max.).
*4. F3SJ operates even when K1 is not connected.
F39-JDA-L F39-JDA-D
*3 *3
*4
