G3PA-(VD)
G3PA-(VD)
134
Output
Model
Applicable load
Load voltage
Load current
Inrush current
G3PA-210B(L)-VD
19 to 264 V
AC (50/60 Hz)
0.1 to 10 A
150 A (60 Hz, 1 cycle)
G3PA-220B(L)-VD
0.1 to 20 A
220 A (60 Hz, 1 cycle)
G3PA-240B(L)-VD
0.5 to 40 A
440 A (60 Hz, 1 cycle)
G3PA-260B(L)-VD
0.5 to 60 A
440 A (60 Hz, 1 cycle)
G3PA-420B-VD
150 to 440 V
AC (50/60 Hz)
0.5 to 20 A
220 A (60 Hz, 1 cycle)
G3PA-430B-VD
0.5 to 30 A
440 A (60 Hz, 1 cycle)
G3PA-420B-VD-2
180 to 528 V
AC (50/60 Hz)
0.5 to 20 A
220 A (60 Hz, 1 cycle)
G3PA-430B-VD-2
0.5 to 30 A
440 A (60 Hz, 1 cycle)
G3PA-450B-VD-2
0.5 to 50 A
440 A (60 Hz, 1 cycle)
Refer to
Engineering Data
for further details.
Characteristics
Item G3PA-
210B(L)-VD
G3PA-
220B(L)-VD
G3PA-
240B(L)-VD
G3PA-
260B(L)-VD
G3PA-
420B-VD
G3PA-
420B-VD-2
G3PA-
430B-VD
G3PA-
430B-VD-2
G3PA-
450B-VD-2
Operate
time
1/2 of load power source cycle + 1 ms max. (DC Input, -B models)
1 1/2 of load power source cycle + 1 ms max. (AC Input)
1 ms max. (-BL models)
Release time
1/2 of load power source cycle + 1 ms max. (DC Input)
1 1/2 of load power source cycle + 1 ms max. (AC Input)
Output ON
voltage drop
1.6 V (RMS) max. 1.8 V (RMS) max.
Leakage
current
5 mA max. (at 120 V
AC)
10 mA max. (at 230 V
AC)
10 mA max. (at 120 V
AC)
20 mA max. (at 230 V
AC)
20 mA max. (at 400 V
AC)
I
2
t
260 A
2
S
810 A
2
S
260 A
2
S
810 A
2
S
810 A
2
S
Insulation
resistance
100 M
Ω
min. (at 500 VDC)
Dielectric
strength
4,000 V
AC, 50/60 Hz for 1 min
Vibration
resistance
Malfunction: 10 to 55 Hz, 0.75-mm double amplitude (mounted to DIN rail)
Shock
resistance
Malfunction: 300 m/s
2
(mounted to DIN rail)
Ambient
temperature
Operating: –30°
C to 80
°
C (with no icing or condensation)
Storage: –30°
C to 100
°
C (with no icing or condensation)
Approved
standards
UL508 File No.E64562, CSA C22.2 (No.14, No.950) File No.LR35535, EN60950 File No.
5915UG
Approval expected in Mar 2000
Ambient
humidity
Operating: 45% to 85%
Weight
Approx.
260 g
Approx.
340 g
Approx.
460 g
Approx.
900 g
Approx.
290 g
Approx.
290 g
Approx.
410 g
Approx.
410 g
Approx.
900 g
