Omron G7L User Manual

G7L
G7L
4
Characteristics
Contact resistance
50 m
"
max.
Operate time
30 ms max.
Release time
30 ms max.
Max. operating frequency
Mechanical: 1,800 operations/hr
Electrical: 1,800 operations/hr (under rated load)
Insulation resistance
1,000 M
"
min. (at 500 VDC)
Dielectric strength
4,000 VAC min., 50/60 Hz for 1 min between coil and contacts
2,000 VAC, 50/60 Hz for 1 min between contacts of same polarity
2,000 VAC, 50/60 Hz for 1 min between contacts of different polarity (DPST-NO model)
Impulse withstand voltage
10,000 V between coil and contact (with 1.2 x 50
'
s impulse wave)
Vibration resistance
Destruction: 10 to 55 Hz, 1.5-mm double amplitude
Malfunction: 10 to 55 Hz, 1.5-mm double amplitude
Shock resistance
Destruction: 1,000 m/s
2
Malfunction: 100 m/s
2
Life expectancy
Mechanical:1,000,000 operations min. (at 1,800 operations/hr)
Electrical: 100,000 operations min. (at 1,800 operations/hr under rated load)
Ambient temperature
Operating: --25
#
Cto60
#
C (with no icing)
Ambient humidity
Operating: 35% to 85%
Weight
Quick-connect terminal models: approx. 90 g
PCB terminal models: approx. 100 g
Screw terminal models: approx. 120 g
Note:
The values given above are initial values.
