Precautions
Safety Relays
A
Safety Relay is a Relay with which a safety circuit can be config
-
ured.
Wiring
Use one of the following wires to connect to the P7SA-10F/10F-
ND/14F/14F-ND.
Stranded
wire:
0.75 to 1.5 mm
2
Solid wire:
1.0 to 1.5 mm
2
Tighten each screw of the P7SA-10F/10F-ND/14F/14F-ND to a
torque
of 0.98 N
S m securely.
Wire
the terminals correctly with no mistakes in
coil polarity
, other
-
wise
the G7SA will not operate.
Cleaning
The
G7SA
is not of enclosed construction. Therefore, do not wash
the
G7SA with water or detergent.
Forcibly Guided Contacts (from EN50205)
If an NO contact becomes welded, all NC contacts will maintain a
minimum distance of 0.5 mm when the
coil is not energized. Like
-
wise
if an NC contact becomes welded, all NO contacts will maintain
a
minimum distance of 0.5 mm when the coil is energized.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To
convert millimeters into inches, multiply by 0.03937. T
o convert grams into ounces, multiply by 0.03527.
Cat. No. J120-E1-1A
