24-hour/Weekly Time Switch H2F 3
■ Characteristics
Note: 1. Accuracy of operating time of when the timer is ON or when the timer is OFF.
2. Difference between the set and actual operation time with the pointer set to the present time.
3. When the timer is used for the first time after energization of 72 hrs.
Item 24-hour operation 1-week operation
Synchronous motor Quartz motor
Accuracy of operating time (see note 1)
±3 min max. ±30 min max.
Influence of voltage
Influence of temperature
Setting error (see note 2)
±3 min max. ±30 min max.
Cyclic error
±3 min max. ±30 min max.
Memory protection against power failure --- 180 hrs min. (see note 3)
Insulation resistance 100 M
Ω min. (at 500 VDC)
Dielectric strength 2,000 VAC, 50/60 Hz for 1 min (between current-carrying terminals and non-current-carrying
metal parts)
1,000 VAC, 50/60 Hz for 1 min (between non-continuous contacts)
Vibration resistance Destruction: 16.7 Hz, 2-mm single amplitude
Malfunction: 10 to 55 Hz, 0.25-mm single amplitude
Shock resistance
Destruction: 1,000 m/s
2
Malfunction: 200 m/s
2
Ambient temperature Operating: –10°C to 55°C
Ambient humidity Operating: 35% to 85%
Life expectancy Contacts: 10,000 operations min.
Motor: 20,000 hours
Approved standards UL917, CSA C22.2 No. 14
Case color Light gray (Munsell 5Y7/1)
Weight Flush mounting: approx. 150 g
Surface mounting:approx. 200 g
