H3FA
H3FA
141
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H3FA-A, H3FA-B, H3FA-SA, H3FA-SB
Twelve, 1.0 dia. holes
Twelve, 1.0 dia. holes
Mounting Holes (Top View)
H3FA-A/-B
H3FA-SA/-SB
Applicable Connecting Socket
Standard 24-pin IC socket can be
used for mounting the time unit.
H3FA-AU, H3FA-BU, H3FA-SAU, H3FA-SBU
Mounting Holes (Top View)
H3FA-AU/-BU
H3FA-
SAU/-SBU
Applicable Connecting Socket
Standard 24-pin IC socket can be
used for mounting the time unit.
Thirteen, 1.0 dia. holes
Thirteen, 1.0 dia. holes
